ACORN EYE 4G Covert Camera
£394.00
20MP 4K Surveillance Camera - 4G & GPS Enabled
The ACORN EYE Covert Camera is a cutting-edge surveillance solution engineered for rugged environments. As the latest evolution in covert 4G camera technology, it delivers ultra-high-definition 4K video, 20MP image capture, and seamless 4G LTE connectivity - all in a compact, waterproof body built for extreme conditions.
Ideal for remote site security, the ACORN EYE provides unmatched clarity, connectivity, and control in the field.
20MP 4K Surveillance Camera - 4G & GPS Enabled
The ACORN EYE Covert Camera is a cutting-edge surveillance solution engineered for rugged environments. As the latest evolution in covert 4G camera technology, it delivers ultra-high-definition 4K video, 20MP image capture, and seamless 4G LTE connectivity - all in a compact, waterproof body built for extreme conditions.
Ideal for remote site security, the ACORN EYE provides unmatched clarity, connectivity, and control in the field.
Key Features
📷 20MP Stills & 4K Video Recording
Captures stunning detail with selectable photo resolutions (4MP to 20MP) and 4K video (3840×2160).
📡 4G LTE Connectivity with GPS
Automatically sends footage and images to the Fortix cloud via FTP transfer with integrated 4G LTE. GPS coordinates are embedded in each file for accurate location tracking.
🌙 Covert Infrared Night Vision
Equipped with 850nm and 940nm invisible IR LEDs, allowing stealthy night monitoring up to 25 metres, without startling wildlife or alerting intruders.
📱 Remote Control via Cloud System & Mobile App
Manage settings, monitor images, and track camera location through the companion mobile app (iOS/Android).
🖥️ External 2.45” Display & Wired Remote
Quick setup and easy file preview using the included colour display and control pad with 6-key interface.
🔄 Simultaneous Video + Snapshot Mode
Automatically captures a still image during video recording—ensuring sharp, framed evidence without motion blur.
🔋 Low-Power Design with Flexible Power Options
Operates on 6x 18650 lithium batteries or 12V–24V DC input, with optional solar compatibility for extended deployment.
☔ Durable IP68 Waterproof Housing
Fully sealed and protected for continuous outdoor use in temperatures from -45°C to +70°C and humidity up to 95%.
TECHNICAL SPECIFICATIONS
| COMPONENT | DETAILS |
| Images Sensor | 8MP Colour CMOS |
| Lens | 120° Wide Angle, F=1.8, Auto IR-Cut |
| Video Resolution | 4K (3840×2160), 2K (2560×1440) |
| Photo Resolution | 4MP / 8MP / 12MP / 16MP / 20MP |
| Snapshot Timing | Still photo at 0.7s into video |
| Trigger Time | 0.4 Seconds |
| Trigger Interval | 0-60 minutes (programmable) |
| Motion Detection | PIR Sensing Distance: 18m, PIR Angle: 15°–100° |
| Infrared Flash | 850nm (25m), 940nm (20m) |
| External Display | 2.45" Colour Screen, 16.7M colours, 6-key control |
| Memory Card Support | 16GB-128GB (SanDisk & Kingston recommended) |
| Network Bands | 4G LTE: B1, B3, B5, B7, B8, B20, B38, B40, B41 |
| Upload Speed | Up to 50Mbps (upstream) |
| Power Supply | 6×18650 Batteries or 12–24V DC (4.0×1.7mm plug) |
| Video Compression | H.265 (smaller file sizes, reduced data usage) |
| Ingress Protection | IP68 Certified |
| Operating Temp | -45°C to +70°C |
| Operating Humidity | 5% to 95% |
| Compliance | FCC, CE, RoHS Certified |
Advanced Capabilities:
- Manual Image Sending: Select and send priority images directly from the device.
- Upgradeable to 5G: Future-ready design allows for 5G module upgrade.
- Ultra-Stealth 940nm Mode: Nearly invisible IR flash for for discreet night operations.
- No Motion Blur: Optimised shutter capture guarantees sharp imagery.
- Time Stamp Metadata: Automatically logs GPS location, date/time, temperature, moon phase, and power status on every capture.
In The Box
- ACORN EYE 4G Covert Camera
- 2.45" Colour Display Unit
- Wired Remote Controller
- Antenna
- Mounting Strap
- Quick Start Guide / User Manual
